Product Features
Set a counter based on the number of screws required to lock the product, effectively preventing missing screws and improving assembly quality.
Five separate lock attachment groups can be set up, and there is no need to reset parameters when replacing lock attachment products. The corresponding groups can be retrieved from the system to improve production efficiency.
Multiple locking parameters can be freely set to customize exclusive locking modes for products, providing flexible and diverse operations for assembly operations.
The speed can be set according to different locking requirements, with 50-1000 (1300-2000) revolutions freely adjustable, achieving multi-purpose use and reducing production costs.
External infrared sensor can be connected to control the fixture switch, making the locking more intelligent. Through LED indicator lights, users can intuitively understand the locking status of screws, effectively reducing human or mechanical operation errors
Product parameters
| model | input voltage | Rated power | Range of torque | Torque adjustment | No load speed（rpm） | Applicable screw diameter（mm） | Suitable for screwdriver heads | |
| kgf.cm | Mechanical teeth | Self attacking teeth | ||||||
| D-Z-0105 | 24V | 25W | 0.1-0.5 | Uninterrupted type | 100-1000 | 1.0-1.2 | 1.0-1.2 | Customized 0 # Head |
| D-Z-0011 | 24V | 25W | 0.1-1.0 | Uninterrupted type | 100-1000 | 1.0-1.5 | 1.0-1.5 | Customized 0 # Head |
