Product Features
Adopting high-performance brushless DC motor, it has the characteristics of low interference, low noise, low vibration, long service life, maintenance free, and meets environmental protection requirements.
The control switch adopts Hall magnetic induction switch and Omron micro switch, which not only considers the service life of the switch, but also effectively ensures the reliability of the product during use.
The top of the motor is equipped with a turbofan to prevent the electric screwdriver from overheating due to long-term continuous use of the product, effectively reducing the temperature of the motor and maintaining normal temperature at the grip.
The reverse switch adopts a patented magnet positioning technology: stable positioning, stable shifting effect, long service life. The brake switch adopts a patented adjustable lever brake technology with a wide adjustment range, which can solve the impact of mechanical wear on the brake without replacing accessories.
The patented ergonomic design of the appearance effectively improves grip comfort, reduces work fatigue, and enhances production efficiency.
A high-precision and stable fine-tuning switch power supply allows the screwdriver speed to be adjusted continuously within a certain range, effectively maintaining product flexibility.
Product parameters
| model | input voltage | Rated power | Range of torque | Torque accuracy% | Torque adjustment | No load speed（rpm） | Applicable screw diameter（mm） | Suitable for screwdriver heads | |
| kgf.cm | Mechanical teeth | Self attacking teeth | |||||||
| D-2408 | 24V | 25W | 0.1-1.0 | ±5 | Uninterrupted type | 100-1000 | 1.0-1.5 | 1.0-1.5 | ?4 |
| D-2409 | 24V | 25W | 0.2-2 | ±5 | Uninterrupted type | 100-1000 | 1.0-2.3 | 1.0-2.0 | ?4 |
| D-2410 | 24V | 25W | 0.3-3 | ±5 | Uninterrupted type | 100-1000 | 1.0-2.3 | 1.0-2.0 | ?4 |
| D-2411 | 24V | 25W | 0.5-5 | ±5 | Uninterrupted type | 100-1000 | 1.4-2.6 | 1.4-2.3 | ?4 |
