Product features
Dynamic real-time display of heating body temperature, setting temperature display and air volume display.
Set temperature and set air gauge storage function.
The automatic protection of the heating material (using pulse heating) can better maintain the heating element, handle and limelight to prolong the service life of the machine.
Built-in advanced microcomputer, digital adjustment/display system.
Built-in temperature sensor, regardless of the amount of air, the output temperature can also be maintained stable.
Body, handle dual regulation, can accurately adjust the air volume and temperature to meet the various types of chip desoldering needs.
After the pull welding is completed, the automatic air supply cooling system works after shutting down. And at this time, the airflow can be adjusted, and the system will be automatically shut down after about a minute.
Product parameters
| Console | spray gun | ||
| power consumption | 3W | power consumption | 520W |
| pump | membrane type | hot air temperature | 100-480 ℃ (using A1126B nozzle) |
| air volume | 28L/min (highest) | ||
| size | 160 * 145 * 225mm | length | 196mm |
| weight | about 4kg | weight | 120g |
