Product features
High-frequency eddy current heating, rapid welding, rapid heating, instant temperature return, accurate temperature control, more stable power, and truly achieve the continuity of lead-free welding.
Sensor front temperature sensitive instantaneous heat compensation.
The heating core is plugged and unplugged to replace the heating core in 2 seconds, and the interior is made of pure silver wire with strong power.
The metal shell has high anti-static level, built-in cooling fan, and the host cools down quickly, which can effectively reduce the life loss of electronic components.
When the welding table is not used, the host automatically enters a dormant state, prolonging the service life of the branded head.
The combination temperature lock is convenient for welding process control.
Equipped with temperature positive holes, the temperature can be corrected at any time to meet the strict requirements of welding temperature for special components.
60 minutes without using the welding table, the main engine automatically shuts down, saving energy and eliminating safety hazards.
Product parameters
| Model | DHS-209C | quality assurance | one year |
| use temperature range | 50-600 ℃ | working voltage | AC220V 50HZ |
| temperature stability (no load) | ± 2 ℃ | maximum instantaneous rate | 90W |
| soldering iron head to ground resistance | < 2 Ω | soldering iron head to ground potential | < 2mV |
| password lock function | There is | automatic sleep function | Yes |
