Product features
Using a pure red trinity digital tube display, the temperature increases or decreases by ± 1 ° C
There is a password locking function, so that the temperature of the welding table cannot be changed at will
Temperature range 180 ℃ -450 ℃
Temperature calibration adopts the method of key input correction value
With PIKE191, the automatic temperature correction function can be realized
Product parameters
| Model | DHS-309R | Power supply voltage | 220V 50Hz AC |
| output voltage | AC 28V | Power | 30W~ 400W Automatic variable power |
| Temperature range | 180~ 450 ℃ | Appearance volume | 135 (W) * 80 (H) * 125 (D) mm |
| Host weight | 1.1KG (without handle) | Welding iron head to ground resistance | ≤ 2Ω (factory value) |
| Welding iron head to ground potential | ≤ 2mV (factory value) | Heating element | 400AH |
| Wire device | 1.3m | Sleep time | 10 minutes (at 25 ℃, no load, this function can be turned off) |
| Temperature rate error | ± 2 ℃ | quality assurance | one year |
