Product features
1. The new height of welding platform technology
This welding table adopts imported chips from the United States, powerful Central Processor, intelligent core control algorithm system, unique dual-channel power supply heating patented technology, 260 watts of instantaneous output power, millisecond temperature compensation response time, integrated hot topic fusion ratio heating core, plug and play quick head change mode, ensuring efficient welding speed and perfect welding quality, greatly improving production efficiency.
2. Heating up in seconds, intelligent compensation, intelligent sleep
Unique dual power supply heating patented technology, it only takes 2.5 seconds to rise from room temperature to 350 degrees. Beyond the heating time of congeneric products 8-20 seconds. During welding, the compensation temperature can be automatically matched within milliseconds according to the heat loss of solder joints and components, without causing virtual welding, false welding, etc. Make precision welding and large pad welding more handy.
When the soldering pen is placed back on the soldering table, it immediately enters a dormant state. The soldering iron head also functions 3-5 times longer than the traditional similar soldering iron head. The output power during dormancy is only 7-10W, and the power consumption is only 1/3 of the traditional soldering table, achieving true low-consumption and high-efficiency welding.
3. Exceed the traditional welding temperature limit
The soldering iron tip and the heating core are integrated in design, with extremely low heat storage and extremely high temperature return rate, so that each point of heat is concentrated on the solder joint, ensuring efficient, stable and safe components during lead-free soldering. Effectively avoid damage to the product due to the increase in grounding resistance and induction voltage after the soldering iron tip is used for a period of time.
4. Ergonomic design, quick head change, handy
The integrated soldering iron head can be quickly replaced as soon as it is plugged and unplugged according to the actual welding environment, solving the cumbersome problem of soldering iron head replacement. The full Chinese menu is adopted, which is more direct and convenient to operate. Comes with temperature correction function, password locking function, welding time statistics function, display screen light switch function, one-click recovery and other functions.
Product parameters
| Model | Power | 130W | |
| Output voltage | 16V + 16V | Temperature range | Set according to working mode (50 ℃ -520 ℃) |
| Maximum ambient temperature | 40 ℃ | Temperature stability | ± 2 ℃ (still air, no load) |
| Soldering iron head to ground resistance | less than 2 ohms | Soldering iron head to ground potential | less than 2 mV |
| Handle wire length | 1.4 meters | Net weight | 2.85KG |
