Product features
The 1.? 0.2mm 191-212 sensor can accurately and quickly measure the temperature of the soldering iron tip, making it suitable for lead-free soldering.
2. Equipped with automatic shutdown function and can set shutdown time.
3. Equipped with "MAX HOLD" maximum temperature holding function.
4. Celsius and Fahrenheit can be converted.
Product parameters
| Model | DHS-506AD | Sensor Type | K Thermocouple |
| Resolution | Temperature Range | ||
| Celsius (° C) | Fahrenheit (° F) | Celsius (° C) | Fahrenheit (° F) |
| 1 ° C | 1 ° F | (0~ 800) ° C | (32~ 1500) ° F |
| Accuracy | Power Supply | 9VDC | |
| Celsius (° C) | Fahrenheit (° F) | Automatic shutdown time range | 001~ 240 minutes |
| ± 5 ° C | ± 9 ° F | Weight | Approx. 200 grams (0.441 lbs) including battery |
| LCD display | Dimensions | ||
| a) Battery voltage low warning display B | b) Sensor damage Display 1 | 85mm (W) * 35mm (H) * 147mm (D) mm | 3.35'x 1.38'x5.79 ' |
