Product features
1. Appearance and construction
◆ The appearance is simple and elegant, stable and elegant. Integrated design of the fuselage, using metal frame structure, high-quality cold-rolled steel electrostatic spraying process, durable.
◆ The top of the unique bending handle, delicate feel, stable and reliable, easy to handle.
◆ Install a user-friendly remote control, which can adjust the air volume and suction force at will.
◆ The product is small in size and does not require installation, which is conducive to a clean and beautiful workspace and easy to move.
2. Fan
◆ DC brushless motor, built-in controller form, performance and quality are more guaranteed.
Stable operation, long working hours. No need for regular maintenance, lower cost.
◆ The wind turbine adopts vortex backward design and special alloy material to effectively prevent the wind turbine from being corroded. The unique dynamic balance correction technology makes the wind turbine run more smoothly and reliably. High air volume, large suction, and higher filtration rate.
3. Filtration system
◆ Adopt quadruple filtration design. Filter layer by layer to ensure that harmful fumes are filtered out more thoroughly. The purification rate can reach 99.97%.
◆ Modular design, layers of protection. Primary, medium and high efficiency can be replaced separately, the filter element has a longer service life and lower replacement cost.
The unique internal sealing structure and special sealing materials enable all harmful substances to pass through the filtration system, resulting in higher filtration efficiency.
Built-in circulation active filtration method avoids venting the indoor air conditioner/heater outdoors, without damaging the temperature and humidity environment in the operating area.
4. Smoke collection device
◆ The machine is equipped with a universal smoking arm, which can change direction and position at will (the length can be customized according to customer requirements). The end is equipped with a new type of smoke hood, which has a unique shape and higher smoking efficiency. Simple installation, convenient use, no need to lay additional pipes.
◆ Simple installation, easy to use, no need to lay additional pipes.
5. Safety certification and design standards, national patents
Compliant with CE, UL, and WHO certifications, safe and reliable.
Dependent design standards: "Indoor Air Quality Standards", GB21551.1-2008, GB/T 18801.
◆ Obtained design patents and machine construction utility model patents issued by the state, counterfeiting must be investigated!
Product parameters
| Model | DHS-2020 | Inlet Air Interface | φ 75mm * 2 Flange |
| Input Voltage | AC220V | Power | 20W-300W |
| Wind Speed | 2 * 13m/s | Filtering Effect | 0.3 μm 99.97% |
| Noise | < 55dB | Smoking Tube Length | ? 75mm * L1.3M |
| System Flow | 12m 3 -400m 3/h | Body Size (mm) | 430 (L) * 240 (W) * 420 (H) |
| Weight (excluding smoking arm) | 16kg | quality assurance | One year |
